708 Knapsack Power Sprayer

708 knapsack power sprayer — a 20 L (customizable) backpack sprayer with aluminum pump head, 8 L/min flow at 25–30 MPa and a 90 cm brass spray gun in the box.

OEM/ODMLogo / Color / Packaging
Stable Supply3000+ Daily Output
Fast DeliveryWithin 30 Days
Global ServiceExported to 60+ Countries
CE
Custom Certification SupportBased on market requirements
Model
Tank Capacity20 L (customizable)
Engine ModelTU26
Rated Power0.7 kW
Displacement25.6 cc
Spray Range7-8 m
Working Pressure25-30 MPa
Flow Rate8 L/min
Plunger Diameter18 mm
Packing Size390×350×645 mm
Tank Capacity20 L (customizable)
Engine Model34F
Rated Power0.75 kW
Displacement25.6 cc
Spray Range7-8 m
Working Pressure25-30 MPa
Flow Rate8 L/min
Plunger Diameter18 mm
Packing Size390×350×645 mm
Tank Capacity20 L (customizable)
Engine Model139
Rated Power0.7 kW
Displacement31 cc
Spray Range7-8 m
Working Pressure25-30 MPa
Flow Rate8 L/min
Plunger Diameter18 mm
Packing Size390×380×645 mm
Tank Capacity20 L (customizable)
Engine Model35
Rated Power0.85 kW
Displacement35.8 cc
Spray Range7-8 m
Working Pressure25-30 MPa
Flow Rate8 L/min
Plunger Diameter18 mm
Packing Size390×350×645 mm

Specifications are for reference only and may vary by configuration or destination market. Contact us for the full data sheet.

708 Knapsack Power Sprayer Overview

The 708 knapsack power sprayer takes the 20 L (customizable) tank size — the balance point between load and refill interval for a full day among trees. Its 18 mm plunger pump runs 25–30 MPa and 8 L/min with a 7–8 m spray range, and the frame accepts four engine options — TU26, 34F, 139 and 35, from 25.6 to 35.8 cc — so output is specified per order without touching the tank or pump layout. Standard fitment includes the aluminum pump head and a 90 cm brass spray gun, with other gun options to order.

OEM & ODM Service

WENXIN has manufactured agricultural and power machinery since 2004, with 1,500+ staff across three production bases covering more than 205,000 m². We support OEM and ODM orders including custom logo, colour, labelling and carton design, and export to over 60 countries. Contact our team with your target market and estimated quantity for factory pricing and lead times.

What is a power sprayer used for?

A power sprayer is suitable for farm spraying, orchard spraying, pest control, crop protection, and large-area agricultural applications.

What engine options are available for power sprayers?

Power sprayers can be equipped with different gasoline engine options, including 2-stroke and 4-stroke engines depending on the model and application.

What is the spraying distance of a power sprayer?

Spraying distance depends on the engine, pump, nozzle, hose, and working pressure. We can provide model-specific spraying distance and pressure data.

How do I choose the right power sprayer model?

You can choose based on engine type, tank capacity, pump pressure, flow rate, spraying distance, and working area. Our team can recommend suitable models for different farm and market needs.

Can you provide OEM power sprayer orders?

Yes. We support OEM/ODM orders for power sprayers, including color, logo, packaging, accessories, and product configuration customization.

01Material InspectionIncoming raw materials and components are inspected against our quality standards before entering production.
02Precision MachiningCore parts are machined in-house on CNC equipment to keep tolerances and performance consistent batch after batch.
03Assembly LineUnits are assembled on dedicated production lines by trained operators, with in-process checks at each station.
04Testing & Running-inEvery unit goes through functional testing and running-in before it is approved for packing.
05Packing & LoadingProducts are packed to export standards, with OEM logo, color and carton design available on request.

Factory audits and video inspections are welcome. Contact us to arrange a visit or a live production walkthrough.
